Dreadbox White Line Mixer

The Dreadbox White Line Mixer is a multi-purpose 3-1 mixer module that provides 9 total inputs and three total outputs.
One of the key tools for any modular system, a mixer provides a simple way of combining and controlling multiple signals from one central source.
The White Lines Mixer comprises of 3 independant 3-1 mixers, with three inputs per channel and a single output per channel.
Each of the top row channels are half normalled to each other;
So if you plug something into channel 1 input 1, but nothing into channel 2 input 1 nor channel 3 input 1, then signal you put into the first channel will appear at the outputs of channels 2 and three.
The outputs of each channel are also normalized in the same way, allowing for the sum of all three channels to go to one master output if none of the outputs from channels 1 and two are connected.
This form of mixer architecture means multiple inputs can be summed to a single output, meaning less cables and an easier, clutter free workflow.
The main features of the Dreadbox White Lines Mixer include
Three channel 3-1 mixer
Channels 1 & 4 on each channel are normalled
6HP wide
Suitable for both CV and audio mixing duties
