RME’s M-16 AD is a 16-channel high-end AD converter, easy to operate yet having a comprehensive feature set.
RME’s M-16 AD is a 16-channel high-end AD converter, easy to operate yet having a comprehensive feature set. The unit combines excellent analog circuit design with the latest converter chips and RME’s superior SteadyClock, resulting in a state-of-the-art AD conversion – 16 times!
The unit’s unique set of features includes analog limiters, three hardware reference levels up to +24 dBu, MADI and ADAT I/O up to 192 kHz, 6.3 mm TRS and D-sub inputs, remote control via MIDI, and operation across a wide range of mains voltages, all packed into a 2U enclosure. An extraordinary limiter, conceived and optimised for professional studio, stage, and broadcast applications, offers essential operational safety with its capability to limit an input’s overload of up to 17 dB without audible distortion (max. input level + 30 dBu).
The M-16 provides multichannel conversion in reference quality – at an unbeatable price/performance ratio!
16-channel* AD converter, fully symmetrical design, 116 dBA
19″ enclosure with only 2 units height
1 x MADI I/O, 32 chanels @ 96 kHz, 16 channels @ 192 kHz
4 x ADAT Out, 16 channels @ 96 kHz, 8 channels @ 192 kHz
Zero Delay MADI I/O: no delay compensation necessary when stacking units
Analog limiter can be activated
16 LED level meters with 5 LEDs each
16 LEDs to display the Limiter state per channel
SteadyClock(TM) – prestine sound quality independently from the quality of the external clock signal
SyncCheck® – unique technology to check clock synchronization
All settings are stored permanently
Fully remote controllable via MIDI and MIDI over MADI
lower power consumption, 40 Watts
